SPEED Software for Electric Machine Design and Analysis. Coupled with Motor-CAD, SPEED is suited for characterising almost all main classes of electric machines and. SPEED is a simple, fast and efficient software based on magnetic equivalent circuitused for sizing or preliminary design of electric motors.

Speed Control Motors For applications where variable speeds are necessary, typically an AC motor with an Inverter or brush motors are used. Brushless DC gear motors are an advanced option due to their wide speed range, low heat and maintenance-free operation. Speed is typically controlled by manual operation on the driver or by an external switch, or with an external 0~10 VDC. Speed control systems typically utilize gearheads to increase output torque. Gear types range from spur, worm or helical / hypoid depending on torque demands and budgets.

Mounting configurations vary to depending on space constraints or design of the application. Our new brushless DC gear motor allows for maximum design efficiency with an AC input driver selection.

Designed to meet an IP66 rating, inch or metric, stainless steel gear shafts, one motor cable connection and a wide variety of wattages and gear types are offered to meet industrial needs. Esf 1.2 3 Ecx Rc2 Big Pack 8.4. Brushless DC Gear Motors offer built-in Hall Effect sensor feedback for speed verification to maintain closed-loop speed regulation. In addition to controlling the motor speed, torque limiting (BLE2) and speed range limit setting, the drivers also offers an alarm function in case any problem occurs during operation.

Inverters with Three-Phase Gear Motors AC gear motors with inverters allow for simple speed control by changing the input frequency or input voltage. Our KIIS Series has been optimally designed for accurate speed control. For larger motor needs, our Brother ie3 motors offer high efficiency motors with Hypoid / Helical gearheads in parallel or right angle mounting configurations. For smaller, compact closed loop applications (6 - 90W), Oriental Motor offers a closed loop package (DSC Series). For larger (100-200W up to 3 HP) requirements, our Three-Phase AC motors with a Frenic-Mini C2 Inverter is ideal.

The Three-Phase KIIS Series offers an optimally designed, high efficiency next generation Three-Phase motor that incorporates higher strength gears, both Parallel Shaft type and new Hypoid Right Angles type that maximizes the motor performance. The KIIS Series is available from 100 W (1/8 HP) up to 200 W (1/4 HP) and features either a parallel or hypoid pre-assembled gear head. High Performance Characteristics have been improved to create a high-performance motor with little speed reduction even with a large load. Boot Skin S on this page. Fanless Design KIIS new motor design reduced heat generation.
